A Square D 3-Phase 480V to 240/120V Transformer is designed to step down 480-volt three-phase power to a 240-volt three-phase secondary with a 120-volt center tap. These transformers are commonly used for commercial, industrial, manufacturing, and electrical distribution applications where both 240V and 120V loads need to be supplied from a three-phase power system.

Electrical Supplies Unlimited carries and sources Square D transformers in a wide range of sizes and configurations, including new, used, surplus, discontinued, and hard-to-find transformers. If you need a Square D 480V to 240/120V transformer for a new installation, replacement project, maintenance application, or emergency repair, contact ESU at 858-558-2850.

Square D 480V to 240/120V Transformer for Sale

One representative Square D transformer in this configuration is the EXN30T6HCT, a 30 kVA dry-type transformer with a 480V delta primary, 240V delta secondary, and 120V center tap. It is designed for low-voltage electrical distribution and uses natural convection cooling. Square D transformers are manufactured by Schneider Electric and are widely used in commercial and industrial electrical systems.

ESU can help locate Square D 480V to 240V transformers, Square D 480V to 240/120V transformers, and other three-phase transformer configurations. Availability can vary by kVA rating, enclosure, winding material, voltage configuration, and whether the transformer is new, used, surplus, or discontinued.



Common Square D 480V to 240/120V Transformer Configurations

  • 15 kVA Square D 480V to 240/120V transformers
  • 30 kVA Square D 480V to 240/120V transformers
  • 45 kVA Square D 480V to 240/120V transformers
  • 75 kVA Square D 480V to 240/120V transformers
  • 112.5 kVA Square D 480V to 240/120V transformers
  • 150 kVA Square D 480V to 240/120V transformers
  • 480V delta primary transformers with 240V delta secondary
  • 240V secondary transformers with 120V center tap
  • Ventilated and non-ventilated Square D transformers
  • New, used, surplus, and obsolete Square D transformers

Square D 3-Phase 480V to 240/120V Transformer Specifications

Specifications vary by model and kVA rating. The Square D EXN30T6HCT is a representative 30 kVA model for this configuration.

  • Manufacturer: Square D / Schneider Electric
  • Transformer Type: Dry-type distribution transformer
  • Phase: Three phase
  • Power Rating: 30 kVA
  • Primary Voltage: 480V delta
  • Secondary Voltage: 240V delta with 120V center tap
  • Frequency: 60 Hz
  • Cooling: Natural convection
  • Windings: Aluminum on the EXN30T6HCT example
  • Temperature Rise: 150°C
  • Insulation: 220°C
  • Primary Taps: Two 2.5% FCAN and four 2.5% FCBN taps
  • DOE Efficiency: Approximately 98.31% for the representative 30 kVA model

Used Square D 480V to 240/120V Transformers

Used Square D 3-phase transformers can be an economical option when replacing an existing transformer or matching older electrical equipment. ESU buys and sells used transformers and can help identify equipment based on the manufacturer's nameplate, kVA rating, primary and secondary voltage, phase, enclosure, and other specifications.

Before installing a used transformer, the equipment should be inspected and evaluated by a qualified electrical professional. The nameplate information should also be carefully compared with the requirements of the electrical system.

Square D Transformer Replacement

Finding the correct replacement transformer requires more than matching the input and output voltage. The kVA rating, phase, frequency, winding configuration, taps, enclosure, temperature rise, physical dimensions, and installation requirements should all be considered.

If you are replacing an older Square D 480V transformer, ESU can help locate a current equivalent or identify a used, surplus, or discontinued transformer that matches the original application. Providing a photograph of the transformer nameplate can make identification much easier.

Obsolete and Hard-to-Find Square D Transformers

Older Square D transformers can become difficult to replace when an original model has been discontinued. ESU specializes in locating obsolete Square D transformers, discontinued transformers, used transformers, surplus transformers, and hard-to-find electrical equipment.

If you cannot find a replacement through normal electrical distribution channels, contact Electrical Supplies Unlimited. We may have the transformer in inventory or be able to locate one through our network of electrical equipment sources.

We Buy Square D Transformers

ESU also buys Square D transformers. If your company has surplus, excess, unused, used, discontinued, or obsolete Square D transformers, contact us to discuss selling the equipment. We purchase electrical equipment from businesses, contractors, industrial facilities, electricians, and other equipment owners.

When contacting us about equipment for sale, provide the manufacturer, model number, kVA rating, voltage, phase, quantity, and condition whenever possible. Photographs of the transformer and nameplate are also helpful.

Why Buy a Square D Transformer from ESU?

  • Over 40 years of experience with electrical equipment
  • New, used, surplus, obsolete, and discontinued equipment
  • Specialization in hard-to-find electrical transformers
  • Square D and Schneider Electric equipment
  • Three-phase and single-phase transformers
  • Commercial and industrial electrical equipment
  • Nationwide service for electricians, contractors, businesses, and industrial customers

Find a Square D 480V to 240/120V Transformer

If you are looking for a Square D 3-phase 480V to 240/120V transformer, contact Electrical Supplies Unlimited at 858-558-2850. Tell us the kVA rating, primary voltage, secondary voltage, phase, and any model or catalog number available from the nameplate.

ESU can help with Square D transformers for new installations, replacements, maintenance projects, equipment upgrades, and hard-to-find applications.
